PASTE BRAZING ALLOYS

In addition to alloys in solid form, we also offer paste brazing alloys.

Brazing paste is a blend of metal brazing alloy powder,
flux and binder that comes in a homogenized, ready-to-use mixture.
Polymers and additives stop the liquid part separating from the solid part
and give the brazing paste its fluid properties.

Pastes can be applied using different methods:

syringed

screen-printing

by roller

sprayed

We can offer pastes tailored to suit the application method due to be employed.
We have an extensive range of binders and brazing pastes
for developing products that can be adapted to suit different processes.

Brazing pastes are particularly suitable for automated applications
as they are easy to integrate into the production process.

They are versatile for both large-scale application and detail work, enabling pinpoint use.

Applications:

Heat exchangers, heating elements,
fashion accessories, costume jewellery, fine jewellery

NICKEL-BASED BRAZING PASTES

COPPER-BASED BRAZING PASTES

SILVER-BASED BRAZING PASTES

NICKEL-BASED BRAZING PASTES

With their innovative composition,
our Nickel-based brazing pastes lend themselves to application using any of the possible methods:
screen-printing
spraying
dipping
roller coating
using dispensers
syringing.
Nickel-based brazing pastes are mainly used in the production
of heat exchangers (EGR coolers) in the automotive industry.

MAIN PROPERTIES

	% Ni	% Cr	% Si	% B	% P	% Fe	MELTING RANGE (C°)	WORKING TEMPERATURE (C°)	DIN EN 1044	ISO 17672
BrazeTec 897 ML 442	76	14	-	-	10	-	890	980	NI 107	Ni 710
BrazeTec 1002 ML 4121	82.4	7	4.5	3.1	-	3	970 - 1000	1050	NI 102	Ni 620
BrazeTec 1080 ML 4127	73.9	14	4.5	3.1	-	4.5	980 - 1070	1175	NI 1A1	Ni 610
BrazeTec 1090	60	30	4	-	6	-	980 - 1040	1090	-	Ni 740
BrazeTec 1130	72	18	8	-	2	-	1050 - 1090	1080	-	-
BrazeTec 1135 ML 4116	70.9	19	10.1	-	-	-	1080 - 1135	1190	NI 105	Ni 650

COPPER-BASED BRAZING PASTES FOR FURNACE BRAZING

Copper-based furnace-brazing pastes offer versatile use:
their distinctive trait is their easy dispensing,
meaning they can be used in various protective atmospheres.
They find wide application in the automotive and heat exchanger industries.

MAIN PROPERTIES

ALLOY	% Cu	% Sn	% P	MELTING RANGE (C°)	WORKING TEMPERATURE (C°)	DIN EN 1044	ISO 17672
ML100	99.9	-	-	1083	1120	CU 101	Cu 110
ML104	96	4	-	960 - 1060	1090	-	-
ML106	94	6	-	910 - 1040	1060	-	-
ML937	94	-	6	710 - 890	850	-	-
ML200	88	12	-	820 - 990	1040	-	-
ML986	86	7	7	650 - 700	840	-	-
ML320	80	20	-	800 - 890	950 - 1000	-	-

SILVER-BASED BRAZING PASTES

Silver-based brazing pastes can be used in the brazing of:

steel, copper and its alloys, or nickel and its alloys.

They can be distributed using automated systems or by means of the screen-printing process.

When it comes to stainless steel brazing, zinc-containing pastes can result in corrosion issues,
and hence we recommend using a zinc-free alloy.

Silver-based brazing pastes usually contain flux and are thus ready to use.

Nonetheless, we can also supply pastes without flux to cater to specific needs.

MAIN PROPERTIES

	% Ag	% Cu	% Zn	% Mn	% Sn	altro	MELTING RANGE (C°)	WORKING TEMPERATURE (C°)	DIN EN 1044	ISO 17672
ML572	72	28	-	-	-	-	780	780	AG 401	Ag 272
BrazeTec D5600	56	22	17	-	5	-	620 - 655	650	AG 102	Ag 156
BrazeTec D4900	49	16	23	7.5	-	4,5 Ni	680 - 705	690	AG 502	Ag 449
